optional integrated water softener.
Simple, Robust, Classeq
Pure Simplicity
Simple to select the right machine for you - easy to install - simple two button operation - easy to clean and maintain.
Excellent Wash Results
Simplicity that delivers. No compromise on wash results - spotlessly clean every time.
Built to Last
Working hard in thousands of kitchens and bars across the globe
The Right Support
Sales & Service teams always on hand to help.
Pure Simplicity
Simple to select the right machine for you - easy to install - simple two button operation - easy to clean and maintain.
Excellent Wash Results
Simplicity that delivers. No compromise on wash results - spotlessly clean every time.
Built to Last
Working hard in thousands of kitchens and bars across the globe
The Right Support
Sales & Service teams always on hand to help.
C500
Simple, Robust and Built to Last
The C500 is compact, simple to use, simple to clean and robust enough to withstand the pressures of any busy kitchen or bar.
Commissioned as a glass or dishwasher on install. As a glasswasher the 500 x 500mm basket can hold 25 pint-sized glasses and wash up to 1,000 glasses per hour. As a dishwasher the basket can hold 18 dinner plates and wash up to 540 plates per hour.
The C500 comes complete with a drain pump, rinse booster pump and detergent and rinse aid pumps with a double skinned door and cabinet to reduce noise and limit heat loss.
Inside, the C500 has new click in, click out wash arms, a new double filtration system, and new moulded wash tank and basket rails, all enhancing wash results and making the machine simple to clean. Reduced rinse water consumption and detergent usage.
Key Features
Dimensions: 600 mm x 600 mm x 820 mm
Basket Size: 500 x 500 mm
C500 technical data at a glance
The new C500 & C500WS can be commissioned on install as a glass or dishwasher. As a glasswasher the C500 can wash up to 1,000 glasses an hour and as a dishwasher up to 540 plates an hour.
Basket Size
500 x 500 mm
Programmes
Glass - 1.5 & 2 minute cycles | Dish - 2, 3 & 5minute cycles
Baskets per hour
Glass 40 | Dish 30
Standard Equipment
Drain pump, rinse booster pump, detergent and rinse aid pumps.
Dimensions
600 mm x 600 mm x 820 mm
Power
30amp or 15amp single phase | 30 Amp 3 phase
Technical Details – C500
Dimensions
- Width: 635 mm
- Height: 1460 mm
- Depth: 712 mm
- Height – Hood
- Open: 1955-2010mm
- Height – Hood
- Closed: 1460-1515mm
- Maximum clear entry height: 440
- Water inlet height floor level: 255-310mm
- Drain height floor level: 0-700mm
- Drain Size: ø 40
- Basket Size: 500 x 500 mm
Performance
- Theoretical max racks/hour: 40
- Plates per rack: 18
- Number of wash programmes: 3
- Duration of wash programmes: 1.5, 3 & 5 minutes
- Noise level: < 70 dB
- Net weight: 130
- Wash pump size: 0.58 kW
- Wash pump capacity: 380 Ltrs/min
- Wash tank heating: 4.05 kW
- Rinse Boiler Heating: 6 kW
- Wash tank capacity: 28 Litres
- Wash tank temperature: 85 °C
- Rinse tank capacity: 7.5 Litres
- Rinse tank temperature: 62 °C
- Rinse water consumption at 3 bar: 3 l
- Rinse booster pump: included
Hydraulic specifications
- Water supply connection G3/4” (3/4”BSP)
- Required water pressure min/max 1-10 bar
- Incoming Water temperature min/max 4°C/55°C
- Drain size 40mm diam.
- Maximum drain height (from machine base) 600mm
- Optional integrated water softener Yes
Electrical specifications
- Amps Required: 20 A
- Operating voltage: 380 – 415V 3N~ / 50Hz
- Total connected load: 6,68 kW
Additional Info
Service: Installation
